S8M-1552-20PK timing Roller Mill Belt
Synchronous teeth on one side, DPK/PK v-ribs on the other.
Features: No slipping, accurate positioning, double-sided drive, overload protection.
Application: Main transmission and roller transmission of flour mills/grinders.
Part Number Explanation:
Timing/Poly V Roller Mill Belt:
For example：1552 S8M-20PK-2
S8M：Tooth type （STD）
8M：Tooth Pitch 8mm
1552：Pitch Length（mm）
30：Number Of Ribs
PK：V-Ribbed Or Profile（Pitch =3.56mm）
-2：Number Of Matched Belts
Flour Roller Mill Belts offer different number of ribs such as 12pk, 16pk, 17pk, 18pk, 20pk, 22pk, 24pk, 26pk, 28pk, 30pk, 32pk, 35pk, 36pk and 38pk, while custom sizes (lengths, widths, ribs and pitches) are available upon request. .
Commonly Roller Mill Belts Size
RPP8M2000-28PK(100mm)
RPP8M1760-36PK（128mm）
RPP8M1760-28PK(100mm)
RPP8M1760-24PK(85mm)
RPP8M1760-21PK(75mm)
RPP8M1600-24PK(85mm)
RPP8M1520-28PK(100mm)
RPP8M1440-28PK(100mm)
RPP8M1440-24PK(85mm)
HTD8M1440-24PK(85mm)
RPP8M1400-28PK(100mm)
RPP8M1368-24PK(85mm)
RPP8M1280-24PK(85mm)
RPP8M1250-24PK(85mm)
RPP8M1200-28PK(100mm)
RPP8M1200-24PK(85mm)
RPP10M-1630-30PK（106.8mm）
S8M-1552-30PK
S8M-1552-16PK
8M-1200-25PK
8M-1200-35PK
8M-1552-16PK
8M-1552-28PK
8M-1552-30PK
8M-1760-28PK
8M-1760-30PK
8M-1760-36PK
8M-1360-36PK
8M-1600-36PK
8M-2800-16PK
8M-2400-14PK
Ordering Guide:
When placing an order, please provide the following information to receive an accurate quote:
Profile and Number of V-Grooves: For example, PK (Double PK) or PL (Double PL), along with the number of V-grooves (e.g., 24V-grooves).
Effective Length: For example, S8M-1552-16PK (1552mm length is typically measured in mm).
Matching Pulleys: If you need to replace your pulleys, Yonghang can also provide matching precision grooved pulleys.
YONGHANG specializes in produce and custom coated transmission belts for 12 years.
