Yonghang New High Quality Measuring Machine For Flat Belts Conveyor Belt
Yonghang's new high-quality measuring machine is a compact, motor-driven device for measuring flat conveyor belts up to 5 meters long and 200 mm wide. The built-in engine and gear provide stable, accurate measurements with adjustable speed and low noise. Robust construction and easy installation make it a space-saving, reliable and cost-effective choice for production lines and quality control.
Features:
Metrology-grade precision
Employing a ±0.1% accuracy standard, this fundamentally eliminates material and time wastage caused by inaccurate measurements – such as conveyor belts being ‘too long requiring trimming’ or ‘too short necessitating scrapping’.
Automated Intelligent Measurement
Fully automated process from belt clamping and automatic traction to length calculation and display. Final length is directly shown on the LCD screen, eliminating manual reading and calculation errors.
Exceptional Repeatability Stability
‘Reliable measurement results’ and ‘convenient measurement process’ are equally vital. Repeatability accuracy of up to ±0.1% ensures stable and dependable outcomes whether operated multiple times by the same individual or by different personnel.
Robust Environmental Adaptability
Operating across a wide temperature range of -20°C to 50°C, it functions reliably in most industrial settings, unaffected by seasonal or workshop temperature fluctuations.
Extensive Application Compatibility
Suitable for flat belts, sidewall belts, and other conveyor belts made from rubber, PVC, PU, canvas, and various composite materials, offering high versatility.
Product parameters:
| Working voltage | 220V |
| Working air pressure | 4KG |
| Power | 650W |
| Measurement range | 200mm Effective width:200mm |
| Length measurement accuracy | ±0.1%Within 5 meters(±1mm);over 5 meters±0.1% |
| Repeatability accuracy | ±0.1% |
| Shaft drive mode | Stepper motor |
| Control system | Liquid crystal screen panel |
| Operating temperature range | -20℃~50℃ |
Precision Rugged Compact Plug-and-Play
Accurate and reliable measurement for flat conveyor belts up to 5 m long and 200 mm wide, reducing setup time and production downtime. Compact, rugged shape with built-in engine and precision gearing delivers industrial-grade quality and a serviceable, sleek style, and units are shipped in protective packaging for safe handling. Easy to mount and integrate into existing lines, it boosts throughput, lowers maintenance needs, and saves calibration labor for tighter process control.
Motorized Precision Belt Measurement
The Yonghang high-quality measuring machine combines an integrated engine with a gear-driven mechanism to handle flat conveyor belts up to 5 meters in length and 200 mm in width, providing consistent, repeatable measurement performance. Its precision gear train and adjustable guiding structure support fast length monitoring and inline quality control, helping to reduce material waste and inspection time. Built on a compact, robust frame with easy-to-adjust belt guides and straightforward maintenance access, the unit is engineered for stable operation in industrial production environments.
Engine Driven Belt Gauge
The Yonghang New High Quality Measuring Machine is a robust unit equipped with an integrated engine and gear system designed for measuring flat conveyor belts. It accurately handles belts up to 5 meters in length and 200 mm in width, providing reliable, repeatable measurements for production and maintenance. Built for durability and ease of use, this compact device streamlines belt inspection and sizing with consistent performance.
◎ product nicety 1
◎ product nicety 2
◎ product nicety 3
Precise, Durable, Efficient, Versatile
Yonghang's new high-quality measuring machine is engineered with an integrated engine and precision gear train to measure flat conveyor belts up to 5 meters long and 200 mm wide, combining robust materials and strict quality control for long service life. It accurately tracks and measures belt length and width while offering smooth, low-vibration operation, adjustable guides for different belt profiles, and straightforward mounting for inline installation. Key features and advantages include a compact footprint, corrosion-resistant housing, easy calibration and maintenance, consistent torque delivery to reduce slippage, and improved production efficiency with lower downtime and total cost of ownership.
Material introduction
The machine’s structural chassis is manufactured from heavy‑gauge steel with a corrosion‑resistant powder coating for rigidity and long service life. Drive elements use hardened alloy steel gears and precision sealed bearings paired with an aluminum gear and engine housing, while measurement contacts and rollers are made from low‑friction, wear‑resistant materials such as UHMW polyethylene or engineered nylon to protect conveyor belts. External components and sensor housings are stainless steel or corrosion‑resistant alloys and critical surfaces are finished to minimize abrasion, making the unit robust and maintenance‑friendly for flat belt conveyors up to 5 meters long and 200 mm wide.
◎ High Grade Alloy
◎ Precision Drive Components
◎ Non-Marring Rubber Plastics
FAQ
YONGHANG specializes in produce and custom coated transmission belts for 12 years.
